| 项目 | 参数 |
|---|
| Frequency Range | 2.400 GHz ~ 2.497 GHz (2.4 GHz ISM Band) |
| Number of Channels | 2.4GHz：Ch1 ~ Ch14 |
| Modulation | 802.11b : DQPSK, DBPSK, CCK |
| 802.11 g/n : OFDM /64-QAM,16-QAM, QPSK, BPSK |
| Output Power | 802.11g /54Mbps : 15 dBm ± 1.5 dB @ EVM ≤ -25dB |
| 802.11n /65Mbps : 14 dBm ± 1.5 dB @ EVM ≤ -28dB |
| Receive Sensitivity (11n,20MHz) @10% PER | - MCS=0 PER @ -85 dBm, typical |
| - MCS=1 PER @ -84 dBm, typical |
| - MCS=2 PER @ -82 dBm, typical |
| - MCS=3 PER @ -80 dBm, typical |
| - MCS=4 PER @ -77 dBm, typical |
| - MCS=5 PER @ -73 dBm, typical |
| - MCS=6 PER @ -71 dBm, typical |
| - MCS=7 PER @ -68 dBm, typical |
| Receive Sensitivity (11g) | - 6Mbps PER @ -86 dBm, typical |
| - 9Mbps PER @ -85 dBm, typical |
| - 12Mbps PER @ -85 dBm, typical |
| - 18Mbps PER @ -83 dBm, typical |
| - 24Mbps PER @ -81 dBm, typical |
| - 36Mbps PER @ -78 dBm, typical |
| - 48Mbps PER @ -73 dBm, typical |
| - 54Mbps PER @ -71 dBm, typical |
| Receive Sensitivity (11b)@8% PER | - 1Mbps PER @ -90 dBm, typical |
| - 2Mbps PER @ -88 dBm, typical |
| - 5.5Mbps PER @ -87 dBm, typical |
| - 11Mbps PER @ -84 dBm, typical |
| Data Rate | 802.11b : 1, 2, 5.5, 11Mbps |
| 802.11g : 6, 9, 12, 18, 24, 36, 48, 54Mbps |
| Data Rate (20MHz ,Long GI,800ns) | 802.11n: 6.5, 13, 19.5, 26, 39, 52, 58.5, 65Mbps |
| Data Rate (20MHz ,short GI,400ns) | 802.11n : 7.2, 14.4, 21.7, 28.9, 43.3, 57.8, 65,72.2Mbps |
| Maximum Input Level | 802.11b : -10 dBm |
| 802.11g/n : -20 dBm |
| Antenna Reference | Small antennas with 0~2 dBi peak gain |
